EarthQuaker Devices Arpanoid | Polyphonic Pitch Arpeggiator

Rate: Adjusts the speed of the sequence.

Toggle: Switch to control the direction of the sequence. All the way left is up, the sequence will continually repeat going up. In the middle is up/down, the sequence will continually repeat going up then back down. All the way right is down, the signal will continually repeat going down.

Step: Selects how many notes there are in the sequence.

Wet: Level control for the effect signal. Unity is around noon.

Mode: 8 position selector switch to choose the octave and key:

1. Major: -1 octave to root.
2. Major: root to +1 octave.
3. Major: -1 octave through +1
4. Major: Random pattern
5. Minor: -1 octave to root.
6. Minor: root to +1 octave.
7. Minor: -1 octave through +1
8. Minor: Random pattern

Dry: Level control for the dry signal. Unity is around noon.

Helpful Tip

We suggest you treat the Arpanoid like a new instrument and take the time to learn how it works. Once you understand how the Arpanoid will work for you, you’ll receive a lifetime of enjoyment from one.
